Lexmark XM3250 - Top Removals; Top Cover Removal

5 Remove the fuser. See “Fuser removal” on page 296.
6 Remove the two screws (B).
7 Remove the redrive gear assembly.
Top removals
Top cover removal
1 Remove the left cover. See “Left cover removal” on page 226.
2 Remove the right cover. See “Right cover removal” on page 237.
7018
Parts removal
297
