Lexmark XM3250 - ADF Roller Removal; ADF Separator Roller Removal

ADF roller removal
Note: For a video demonstration, see ADF roller removal.
1 Open the ADF door.
2 Release, and then rotate the retainers as shown.
3 Remove the ADF roller.
Note: For a video demonstration, see
ADF roller removal at infoserve.lexmark.com/ids/sma.
ADF separator roller removal
Note: For a video demonstration, see ADF separator roller removal.
1 Open the ADF door.
2 Release the latches, and then remove the roller.
Installation note: Make sure that the spring is properly installed.
7018
Parts removal
306
