Lexmark XM3250 - Sensor (Paper Present) Removal

c Apply RheoGel 793 to the point of contact to the lower edge (B), where the wiper bracket glides.
B
A
Sensor (paper present) removal
1 Remove the rear cover. See “Rear door and cover removal” on page 295.
2 Remove the power supply. See “Power supply removal” on page 273.
3 Remove the duplex. See “Duplex removal” on page 275.
7018
Parts removal
285
