Lexmark XM3250 - Internal Solutions Port Does Not Operate Correctly; Defective Flash Detected

3 Remove the four screws (B).
B
4 Remove the screw (C).
C
5 Remove the fuser actuator.
Installation note: To test if the actuator is properly installed, push, and then release the actuator (A). The
actuator should bounce back.
7018
Parts removal
232
