Connector Connects to Pin no. Signal
JFAN1 Cooling fan 1 V_MAIN_FAN24V
2Ground
3 MAIN_FAN_ENC_R
JEXIT1 Sensor (exit) 1 V_5V_PAPER_OUT
2 S_PAPER_OUT_C
3Ground
JUSBD1 USB connector with flange 1 V_USBD_5V
2 USB_DEV_N
3 USB_DEV_N
4 USB_DEV_GND
JRIP1 Debug port 1 Ground
2RXD0_RIP_CN
3TXD0_RIP_CN
4JRIP_100_+5V
JOPT1 Resettable fuse 1 24V_F_OPT
2S_OPT_TXR
3S_INPUT_FDT
4S_OPT_RXR
5Ground
65V_PHD
JTDS1 Sensor (toner density) 1 S_TDS_LED_PWM
2 S_A_TDS_C
3 no connection
4V_TDS+5V_C
JDUPPI1 Sensor (duplex and input) 1 V_5V_DUPLEX
2 S_DUPLEX_C
3 no connection
4V_5V_DUPLEX
5 S_PAPER_IN_C
6Ground
JFEED1 Feed solenoid 1 V_FDSOL +24V_MSF
2V_FDSOL
7018
