Assembly 1: Covers
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X1343 1 1 Top cover
“Top cover removal” on page 297
2 40X9102 1 1 Output extender --
3 41X1357 1 1 Rear door and cover
“Rear door and cover removal” on
page 295
4 41X2275 1 1 Rear access door --
540X8521 1 1Dust cover --
6 41X1166 1 1 Right cover
“Right cover removal” on page 237
7 41X1233 1 1 Controller board access
cover
“Right cover removal” on page 237
8 41X1164 1 1 Nameplate
“Nameplate removal” on page 252
9 41X1168 1 1 Left cover
“Left cover removal” on page 226
10 41X1358 1 1 Top access cover
“Top access cover removal” on
page 254
11 41X2501 1 1 Scanner rear cover
“Scanner rear cover removal” on
page 294
