Assembly 2: Control panel
Asm-index P/N Units/mach Units/FRU Description Removal procedure
141X2439 1 1Bezel (MX622)
“Bezel removal” on page 255
1 41X2609 1 1 Bezel (XM3250)
“Bezel removal” on page 255
2 41X2440 1 1 Control panel covers
and hinges
“Control panel covers and buttons
removal” on page 257
3 41X0051 1 1 Control panel display
assembly
“Control panel display assembly
removal” on page 255
4 41X2232 1 1 Control panel flat cable
“Control panel flat cable removal” on
page 262
541X2230 1 1Speaker
“Speaker removal” on page 260
6 41X1354 1 1 Control panel rear
cover
“Control panel covers and buttons
removal” on page 257
7 41X1345 1 1 Scanner front cover
“Scanner front cover removal” on
page 260
8 41X0543 1 1 Control panel front
cover
“Control panel covers and buttons
removal” on page 257
7018
Parts catalog
392
