Assembly 3: Electronics 1
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X1185 1 1 Printhead
“Printhead removal” on page 302
2 41X1178 1 1 Fuser, 110V
“Fuser removal” on page 296
2 41X1179 1 1 Fuser, 220V
“Fuser removal” on page 296
2 41X1180 1 1 Fuser, 100V
“Fuser removal” on page 296
3 41X1363 1 1 Controller board
“Controller board removal” on page
244
4 41X1201 1 1 Power supply,
100V/110V
“Power supply removal” on page 273
4 41X1202 1 1 Power supply, 220V
“Power supply removal” on page 273
5 41X1224 1 1 Main drive gearbox
“Main drive gearbox removal” on
page 227
