Assembly 8: Paper transport 2
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8393 1 1 Transfer roller
“Transfer roller removal” on page 264
2 41X1197 1 1 MPF pick roller and
separator pad
“MPF pick roller and separator pad
removal” on page 267
3 41X1196 1 1 Pick roller assembly
“Pick roller assembly removal” on
page 280
441X1198 2 2Pick tire --
5 41X1371 1 1 Redrive assembly
“Redrive assembly removal” on
page 295
7018
Parts catalog
404
