Assembly 14: Staple finisher (right)
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8144 1 1 Stapler interface cable
“Stapler interface cable removal” on
page 347
2 40X7592 1 1 Sensor (stapler access
door)
“Sensor (stapler access door) removal”
on page 331
3 40X8139 1 1 Stapler door close limit
switch with cable
“Stapler door close limit switch
removal” on page 333
4 40X8142 1 1 Stapler carriage
assembly
“Stapler carriage assembly removal”
on page 331
540X8130 1 1Stapler right cover
“Stapler right cover removal” on
page 328
6 40X8129 1 1 Stapler cartridge
access door
“Stapler cartridge access door
removal” on page 326
7 40X8149 1 1 Staple roll holder
“Staple roll holder removal” on
page 327
7018
Parts catalog
416
