Assembly 15: Staple finisher (top)
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8140 1 1 Stapler service cover
“Stapler service cover removal” on
page 341
2 40X8141 1 1 Stapler top cover
“Stapler top cover removal” on page
349
3 40X8137 1 1 Stapler controller
board
“Stapler controller board removal” on
page 341
4 40X8125 1 1 Stapler tamper motor
“Motor (stapler left tamper) removal” on
page 341 or “Motor (stapler right tamper)
removal” on page 342
5 40X8131 1 1 Sensor (stapler bin full
send)
“Sensor (stapler bin full send) removal”
on page 354
6 40X8132 1 1 Sensor (stapler bin full
receive)
“Sensor (stapler bin full receive)
removal” on page 352
7018
Parts catalog
418
