Assembly 16: Staple finisher (rear)
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8148 1 1 Stapler cooling fan
“Stapler cooling fan removal” on
page 345
2 40X8135 1 1 Stapler power supply
unit
“Stapler power supply unit removal”
on page 345
2 40X8540 1 1 Stapler power supply
unit—China
“Stapler power supply unit removal”
on page 345
3 40X8128 1 1 Stapler rear door
“Stapler rear door removal” on
page 330
4 40X8458 1 1 Trapped staple access
door
“Trapped staple access door removal”
on page 340
5 40X8134 1 1 Sensor (stapler pass
through)
“Sensor (stapler pass through)
removal” on page 357
6 40X8138 1 1 Stapler rear door close
limit switch with cable
“Stapler rear cover close limit switch
removal” on page 343
7 40X7592 1 1 Sensor (stapler rear
door)
“Sensor (stapler rear cover) removal”
on page 338
7018
Parts catalog
420
