Assembly 18: Staple finisher tamper assembly
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8754 1 1 Sensor (stapler
paddle HP)
“Sensor (stapler paddle HP) removal” on
page 368
2 40X8754 1 1 Sensor (stapler left
tamper HP)
“Sensor (stapler left tamper HP)
removal” on page 367
3 40X8750 2 2 Stapler tamper drive
belt
“Tamper drive belt removal” on
page 362
4 40X8754 1 1 Sensor (stapler right
tamper HP)
“Sensor (stapler right tamper HP)
removal” on page 366
5 40X8125 2 1 Stapler tamper motor
“Motor (stapler left tamper) removal” on
page 341 or “Motor (stapler right
tamper) removal” on page 342
6 40X8749 1 1 Tamper sub-assembly
“Tamper sub-assembly removal” on
page 360
