RS-485 Communication Features
255
Comm. Address
Parameter
Scale
Unit
Assigned Content by Bit
0h0393
Rev Pos
Torque Limit
0.1
%
Reverse motoring torque limit
0h0394
Rev Neg
Torque Limit
0.1
%
Reverse regenerative torque limit
0h0395
Torque Bias
0.1
%
Torque bias
0h0396- 0h399
Reserved
-
-
-
0h039A
Anytime Para
-
-
Set the CNF.20
*
value (refer to 5.37 Operation State
Monitor on page 203)
0h039B
Monitor Line-
1
-
-
Set the CNF.21
*
value (refer to 5.37 Operation State
Monitor on page 203)
0h039C
Monitor Line-
2
-
-
Set the CNF.22
*
value (refer to 5.37 Operation State
Monitor on page 203)
0h039D
Monitor Line-
3
-
-
Set the CNF.23
*
value (refer to 5.37 Operation State
Monitor on page 203)
* Displayed on an LCD keypad only.
Note
A frequency set via communication using the common area frequency address (0h0380, 0h0005) is not
saved even when used with the parameter save function. To save a changed frequency to use after a
power cycle, follow these steps:
1 Set dr.07 to Keypad-1 and select a random target frequency.
2 Set the frequency via communication into the parameter area frequency address (0h1101).
3 Perform the parameter save (0h03E0: '1') before turning off the power. After the power cycle, the
frequency set before turning off the power is displayed.
7.5.3 Inverter Memory Control Area Parameter (Read and Write)
Comm.
Address
Parameter
Scale
Unit
Changeable
During Operation
Function
0h03E0
Save parameters
-
-
X
0: No, 1:Yes
0h03E1
Monitor mode
initialization
-
-
O
0: No, 1:Yes
0h03E2
Parameter
initialization
-
-
X
0: No, 1: All Grp, 2: Drv Grp
3: bA Grp, 4: Ad Grp, 5: Cn Grp
6: In Grp, 7: OU Grp, 8: CM Grp
9: AP Grp, 12: Pr Grp, 13: M2 Grp
Setting is prohibited during
fault trip interruptions.
