Table of Functions
307
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property
*
V/F SL Ref.
30 0h1C1E
Electronic
thermal
continuous
rating
M2-ETH
Cont
50-150(%) 100 X/A O I p.177
40 0h1C28
Rotation count
speed gain
Load Spd
Gain
0~6000.0[%] 100.0 O/A O I -
41 0h1C29
Rotation count
speed scale
Load Spd
Scale
0
x 1
0: x 1 O/A O I -
1
x 0.1
2
x 0.01
3
x 0.001
4
x 0.0001
42 0h1C2A
Rotation count
speed unit
Load Spd
Unit
0
Rpm
0: rpm O/A O I -
1
mpm
8.12 User Sequence group (US)
This group appears when AP.02 is set to 1 (Yes) or CM.95 is set to 2 (P2P Master). The parameter
cannot be changed while the user sequence is running.
SL: Sensorless vector control function (dr.09) , I – IM Sensorless, P – PM Sensorless
*O/X: Write-enabled during operation, 7/L/A: keypad/LCD keypad/common
Code
Comm.
Address
Name
LCD Display
Setting
Range
Initial
Value
Property*
V/F
SL
Ref.
00
-
Jump code
Jump Code
1-99
31
O/A
O
I/P
p.48
01
0h1D01
User sequence
operation
command
User Seq Con
0
Stop
0:Stop
X/A
O
I/P
p.112
1
Run
2
Digital In
Run
02
0h1D02
User sequence
operation loop
time
US Loop Time
0
0.01s
1:0.02s
X/A
O
I/P
p.112
1
0.02s
2
0.05s
3
0.1s
4
0.5s
5
1s
11
0h1D0B
Output address
link1
Link UserOut1
0-0xFFFF
0
X/A
O
I/P
p.112
12
0h1D0C
Output address
link2
Link UserOut2
0-0xFFFF
0
X/A
O
I/P
p.112
13
0h1D0D
Output address
link3
Link UserOut3
0-0xFFFF
0
X/A
O
I/P
p.112
