Table of Functions
305
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property
*
V/F SL Ref.
93
67
0h1B5D Fault history 3 - - - -/7 O O -
94
67
0h1B5E Fault history 4 - - - -/7 O O -
95
67
0h1B5F Fault history 5 - - - -/7 O O -
96
67
0h1B60
Fault history
deletion
-
0 No
0:No -/7 O O -
1
Yes
8.11 2nd Motor Function group (PAR→M2)
The 2nd Motor function group will be displayed if any of In.65-71 are set to 26 (2nd MOTOR). In the
following table, the data shaded in grey will be displayed when a related code has been selected.
SL: Sensorless vector control (dr.09) , I – IM Sensorless, P – PM Sensorless
*O/X: Write-enabled during operation, 7/L/A: Keypad/LCD keypad/Common
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property
*
V/F SL Ref.
00
-
Jump Code
Jump Code
1-99
14
O/A
O
I
p.48
04 0h1C04
Acceleration
time
M2-Acc Time 0.0-600.0(s) 20.0 O/A O I p.177
05 0h1C05
Deceleration
time
M2-Dec
Time
0.0-600.0(s) 30.0 O/A O I p.177
06 0h1C06 Motor capacity M2-Capacity
0
0.2 kW
- X/A O I p.177
1
0.4 kW
2
0.75 kW
3
1.1 kW
4
1.5 kW
5
2.2 kW
6
3.0 kW
7
3.7 kW
8
4.0 kW
9
5.5 kW
10
7.5 kW
11
11.0 kW
12
15.0 kW
13
18.5 kW
14
22.0 kW
15
30.0 kW
07 0h1C07 Base frequency
M2-Base
Freq
30.00-
400.00(Hz)
60.00 X/A O I p.177
