LSIS LSLV-S100 Operation Manual

276
Table of Functions
8.5 Control Function group (PAR→Cn)
In the following table, the data shaded in grey will be displayed when a related code has been
selected.
SL: Sensorless vector control (dr.09) , I – IM Sensorless, P – PM Sensorless
*O/X: Write-enabled during operation, 7/L/A: Keypad/LCD keypad/Common
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property
*
V/F SL Ref.
00
-
Jump Code
Jump Code
1-99
4
O/A
O
I/P
p.48
04 0h1404
Carrier
frequency
Carrier Freq
Heavy
Duty
V/F:
1.0~15.
0
(kHz)
27
IM:
2.0~15.
0
(kHz)
PM:
2.0~10.
0(kHz)
3.0
X/A O I/P
p.176
Normal
Duty
28
V/F:
1.0~ 5.0
(kHz)
29
IM:
2.0~5.0
(kHz)
2.0 p.176
05 0h1405 Switching mode PWM Mode
0
Normal
PWM
0:Norm
al PWM
X/A O I p.176
1
Lowlea
kage
PWM
09
30
0h1409
Initial excitation
time
PreExTime 0.00-60.00(s) 1.00 X/A X I p.150
10
30
0h140A
Initial excitation
amount
Flux Force 100.0-300.0(%) 100.0 X/A X I p.150
27
In case of 0.4~4.0kW, the setting range is 2.0~15.0(kHz).
28
PM synchronous motor sensorless vector control mode does not support normal duty
operation [when dr.09 (Control Mode) is set to 6 (PM Sensorless)].
29
In case of 0.4~4.0kW, the setting range is 2.0~5.0(kHz).
30
Displayed when dr.09 (Control Mode) is not set to 6 (PM Sensorless).
