LSIS LSLV-S100 Operation Manual

83
Learning Basic Features
4.6 Local/Remote Mode Switching
Local/remote switching is useful for checking the operation of an inverter or to perform an
inspection while retaining all parameter values. Also, in an emergency, it can also be used to
override control and operate the system manually using the keypad.
The [ESC] key is a programmable key that can be configured to carry out multiple functions. For
more details, refer to 3.2.4 Configuring the [ESC] Key on page 50
.
Group
Code
Name
LCD Display
Parameter Setting
Setting Range
Unit
dr
90
[ESC] key functions
-
2
Local/Remote
0–2
-
Operation
drv
Command source
Cmd
Source*
1
Fx/Rx-1
0–5
-
* Displayed under DRV-06 on the LCD keypad.
Local/Remote Mode Switching Setting Details
Code
Description
dr.90
[ESC] key functions
Set dr.90 to 2(Local/Remote) to perform local/remote switching using the [ESC]
key. Once the value is set, the inverter will automatically begin operating in
remote mode. Changing from local to remote will not alter any previously
configured parameter values and the operation of the inverter will not change.
Press the [ESC] key to switch the operation mode back to “local.” The SET light will
flash, and the inverter will operate using the [RUN] key on the keypad. Press the
[ESC] key again to switch the operation mode back to “remote.” The SET light will
turn off and the inverter will operate according to the previous drv code
configuration.
Note
Local/Remote Operation
• Full control of the inverter is available with the keypad during local operation (local operation).
• During local operation, jog commands will only work if one of the P1–P7 multi-function terminals
(codes In.65–71) is set to 13(RUN Enable) and the relevant terminal is turned on.
• During remote operation (remote operation), the inverter will operate according to the previously
set frequency reference source and the command received from the input device.
• If Ad.10 (power-on run) is set to 0(No), the inverter will NOT operate on power-on even when the
following terminals are turned on:
- Fwd/Rev run (Fx/Rx) terminal
- Fwd/Rev jog terminal (Fwd jog/Rev Jog)
- Pre-Excitation terminal
To operate the inverter manually with the keypad, switch to local mode. Use caution when
switching back to remote operation mode as the inverter will stop operating. If Ad.10 (power-on
