LumaSense LumaSMART User Manual

LumaSMART
®
User Manual Modbus Protocol Testing • 91
12
Analog Output FOT 4
Minimum Current
Int16
FOT 4
Channels 13
-> 16
13
Analog Output FOT 4
Maximum Current
Int16
14
Analog Output FOT 4
Minimum Temperature
Int16
15
Analog Output FOT 4
Minimum Temperature
Int16
16 - 63 Reserved for future expansion
64
Configuration Relay 1
0 = Disabled
1 = Normally Deenergized
2 = Normally Energized
Int16
Relay 1
65 Alarm Set Point for Relay 1 Int16
66 Restore Set Point for Relay 1 Int16
67
Channels Driving Relay 1
MSB = CH16 / LSB = CH1
Int16
Bit Mapped
68
Control Setting for Relay Number 1
2 = OR Logic
1 = AVG Logic
Int16
69
Configuration Relay 2
0 = Disabled
1 = Normally Deenergized
2 = Normally Energized
Int16
Relay 2
70 Alarm Set Point for Relay 2 Int16
71 Restore Set Point for Relay 2 Int16
72
Channels Driving Relay 2
MSB = CH16 / LSB = CH1
Int16
Bit Mapped
73
Control Setting for Relay Number 2
2 = OR Logic
1 = AVG Logic
Int16
