LumaSense LumaSMART User Manual

LumaSMART
®
User Manual Modbus Protocol Testing • 92
74
Configuration Relay 3
0 = Disabled
1 = Normally Deenergized
2 = Normally Energized
Int16
Relay 3
75 Alarm Set Point for Relay 3 Int16
76 Restore Set Point for Relay 3 Int16
77
Channels Driving Relay 3
MSB = CH16 / LSB = CH1
Int16
Bit Mapped
78
Control Setting for Relay Number 3
2 = OR Logic
1 = AVG Logic
Int16
79
Configuration Relay 4
0 = Disabled
1 = Normally Deenergized
2 = Normally Energized
Int16
Relay 4
80 Alarm Set Point for Relay 4 Int16
81 Restore Set Point for Relay 4 Int16
82
Channels Driving Relay 4
MSB = CH16 / LSB = CH1
Int16
Bit Mapped
83
Control Setting for Relay Number 4
2 = OR Logic
1 = AVG Logic
Int16
84
Configuration Relay 5
0 = Disabled
1 = Normally Deenergized
2 = Normally Energized
Int16
Relay 5
85 Alarm Set Point for Relay 5 Int16
86 Restore Set Point for Relay 5 Int16
87
Channels Driving Relay 5
MSB = CH16 / LSB = CH1
Int16
Bit Mapped
88
Control Setting for Relay Number 5
2 = OR Logic
1 = AVG Logic
Int16
