User Manual Modbus Protocol Testing • 93
89
Configuration Relay 6
0 = Disabled
1 = Normally Deenergized
2 = Normally Energized
Int16
Relay 6
90 Alarm Set Point for Relay 6 Int16
91 Restore Set Point for Relay 6 Int16
92
Channels Driving Relay 6
MSB = CH16 / LSB = CH1
Int16
Bit Mapped
93
Control Setting for Relay Number 6
2 = OR Logic
1 = AVG Logic
Int16
94
Configuration Relay 7
0 = Disabled
1 = Normally Deenergized
2 = Normally Energized
Int16
Relay 7
95 Alarm Set Point for Relay 7 Int16
96 Restore Set Point for Relay 7 Int16
97
Channels Driving Relay 7
MSB = CH16 / LSB = CH1
Int16
Bit Mapped
98
Control Setting for Relay Number 7
2 = OR Logic
1 = AVG Logic
Int16
99
Configuration Relay 8
0 = Disabled
1 = Normally Deenergized
2 = Normally Energized
Int16
Relay 8
100 Alarm Set Point for Relay 8 Int16
101 Restore Set Point for Relay 8 Int16
102
Channels Driving Relay 8
MSB = CH16 / LSB = CH1
Int16
Bit Mapped
103
Control Setting for Relay Number 8
2 = OR Logic
1 = AVG Logic
Int16
