LumaSense LumaSMART User Manual

LumaSMART
®
User Manual Modbus Protocol Testing • 94
104
Configuration Relay 9
0 = Disabled
1 = Normally Deenergized
2 = Normally Energized
Int16
Relay 9
105 Alarm Set Point for Relay 9 Int16
106 Restore Set Point for Relay 9 Int16
107
Channels Driving Relay 9
MSB = CH16 / LSB = CH1
Int16
Bit Mapped
108
Control Setting for Relay Number 9
2 = OR Logic
1 = AVG Logic
Int16
109
Configuration Relay 10
0 = Disabled
1 = Normally Deenergized
2 = Normally Energized
Int16
Relay 10
110 Alarm Set Point for Relay 10 Int16
111 Restore Set Point for Relay 10 Int16
112
Channels Driving Relay 10
MSB = CH16 / LSB = CH1
Int16
Bit Mapped
113
Control Setting for Relay Number 10
2 = OR Logic
1 = AVG Logic
Int16
114
Configuration Relay 11
0 = Disabled
1 = Normally Deenergized
2 = Normally Energized
Int16
Relay 11
115 Alarm Set Point for Relay 11 Int16
116 Restore Set Point for Relay 11 Int16
117
Channels Driving Relay 11
MSB = CH16 / LSB = CH1
Int16
Bit Mapped
118
Control Setting for Relay Number 11
2 = OR Logic
1 = AVG Logic
Int16
