2250 SERVICE/MAINTENANCE MANUAL POWER TRAIN
7
Table 7-4 Engine Fault Codes
Fault
Code
Light Fault
Fault
Code
Light Fault
111 Red Controller#1 312 Yellow Injector Cylinder #5
115 Red Engine Speed 313 Yellow Injector Cylinder #3
121 Yellow Engine Speed 314 Yellow Injector Cylinder #6
122 Yellow Boost Pressure 315 Yellow Injector Cylinder #2
123 Yellow Boost Pressure 321 Yellow Injector Cylinder #4
131 Red Percent Accelerator Pedal Position 322 Yellow Injector Cylinder #1
132 Red Percent Accelerator Pedal Position 323 Yellow Injector Cylinder #5
135 Yellow Engine Oil Pressure 324 Yellow Injector Cylinder #3
141 Yellow Engine Oil Pressure 325 Yellow Injector Cylinder #6
143 Engine
Protection
Engine Oil Pressure 331 Yellow Injector Cylinder #2
144 Yellow Engine Coolant Temperature 332 Yellow Injector Cylinder #4
145 Yellow Engine Coolant Temperature 343 Yellow Controller #1
151 Engine
Protection
Engine Coolant Temperature 269 Red (Blink) Anti-Theft Start Inhibit (Password
Valid Indicator)
153 Yellow Intake Manifold Temperature 352 Yellow 5 Volts DC Supply
154 Yellow Intake Manifold Temperature 415 Engine
Protection
Engine Oil Pressure
155 Engine
Protection
Intake Manifold Temperature 422 Yellow Coolant Level
212 Yellow Engine Oil Temperature 326 None SAE J1939 Datalink
213 Yellow Engine Oil Temperature 327 Yellow SAE J1939 Datalink
214 Engine
Protection
Engine Oil Temperature 431 Yellow Percent Accelerator Pedal Position
221 Yellow Barometric Pressure 432 Red Percent Accelerator Pedal Position
222 Yellow Barometric Pressure 433 Yellow Boost Pressure
234 Red Engine Speed
235 Engine
Protection
Coolant Level
241 Yellow Road Speed
243 Yellow Engine Retarder Status
245 Yellow Fan Clutch Output Device Driver
254 Red Fuel Shutoff Valve
311 Yellow Injector Cylinder #1
