Manitowoc 2250 Service And Maintenance Manual

Reference Only
Manitowoc Published 11-06-15, Control # 040-13 10-45
2250 SERVICE/MAINTENANCE MANUAL TROUBLESHOOTING
10
Test 11 — Manually Stroking the Pump
See Test 9 — Location of Pump Ports for location of pump
ports. To stroke the pump:
• Start with engine running and all brakes and locks
engaged.
• Rotate the pump manual override in the clockwise
direction to load down and raise pressure in port “A”.
• Rotate the pump manual override in the counter-
clockwise direction to load down and raise pressure in
port “B”.
Item Description
1 Manual stroke override
2 Pump EDC
2
P966
1
