TROUBLESHOOTING 2250 SERVICE/MAINTENANCE MANUAL
10-36
Published 11-06-15, Control # 040-13
Test 2 — Checking Resistance at Engine Temperature Switch
Set digital multi-meter to test resistance. Make required
connections to test lead adapter at the meter. Connect
negative lead to a grounded component on the crane and
the positive lead to engine temperature switch wire terminal.
With engine cold, check for a resistance of approximately
0.67 ohms.
Item Description
1 Temperature switch
