Manitowoc Published 11-06-15, Control # 040-13 7-11
2250 SERVICE/MAINTENANCE MANUAL POWER TRAIN
7
Item1 Description
1 Air Cleaner Assembly
1a Service Cover
1b Latch (6)
1c Primary Filter (2)
1d Secondary Filter (2)
1e Housing
2 Steel Tube
3Clamp
4 Rubber Reducer
5 Rubber Elbow Reducer (2)
6Engine Intake
7 Mounting Lugs (8)
8 Service Indicator
8a Service Window
8b Reset Button
8
8b
8a
1c
1d
Removal Tabs
1e
1b
3
5
3
3
3
1
4
6
8
2
5
2
1a
7 (4 this side,
4 on opposite side)
FIGURE 7-10
AIR CLEANER — TIER 4 ONLY
1
1a
