TROUBLESHOOTING 2250 SERVICE/MAINTENANCE MANUAL
10-40
Published 11-06-15, Control # 040-13
Test 6 — Cleaning and Adjusting the Engine RPM Transducer
To clean and adjust engine RPM transducer:
• Loosen the lock nut and remove threaded transducer
from flywheel housing.
• Clean any metallic debris from the magnetic pickup on the
transducer with a cleaning solvent.
• Reinstall the transducer so magnetic pickup makes
contact with flywheel.
• Back off flywheel 1/2 turn and secure lock nut.
Item Description
1 Flywheel housing
2 RPM transducer
3 Lock nut
P933
2
3
1
