Manitowoc 2250 Service And Maintenance Manual

Reference Only
ELECTRIC SYSTEM 2250 SERVICE/MAINTENANCE MANUAL
3-46
Published 11-06-15, Control # 040-13
Drum Identification
Drum
Number
2250 and
MAX-ER 225 or 400
MAX-ER 2000 50,000 lb Clam
1 Front Load Drum No Drum Available Front Load Drum
2
Rear or Right Rear
Load Drum
Boom Hoist
Full Width Rear Load
Drum
3
Left Rear Load Drum
or
Mast Hoist (MAX-ER)
Rear Load Drum
with Luffing Hoist
—
4 Boom Hoist Mast Hoist Boom Hoist
5 Luffing Hoist
Luffing Hoist or
Rear Load Drum or
Auxiliary Drum
without Luffing Hoist
Tagline
9 — Front Load Drum —
FIGURE 3-17
Drum on Adapter Frame
Drums on Crane
50,000 lb Clam
MAX-ER 2000 Attachment
5
1
3
2
4
3
2
4
1
2
4
Drum in Boom Butt
9
5
No Drum Here
MAX-ER 225 or 400
2250 and
or or
5
Drum on Adapter Frame
Drums on Crane
Drums on Crane
Drum on Adapter Frame
