Manitowoc Published 11-06-15, Control # 040-13 3-45
2250 SERVICE/MAINTENANCE MANUAL ELECTRIC SYSTEM
* = Optional
Table 3-5Table Note and Abbreviations
BATTERY VOLTAGE LOW System voltage below 11 volts. Handle commands disabled.
IO BOARD FAULT n CPU not communicating with I/O board n,
where:
1 – first I/O board after the CPU
2 – second I/O board after the CPU
4 – third I/O board after the CPU
8 – fourth I/O board after the CPU
Failure of more than one board is
indicated by an n value that is the sum of
the n values associated with each board
(I.e. if n=6, the second and third I/O
boards after the CPU may have failed)
Check for loose or damaged I/O board.
Reposition and reconnect the boards in the
circuit to see if the problem moves with the
location. If the indicated fault code n does not
change, the problem is most likely in the
motherboard or the CPU board.
See procedures in Folio 2238 at the end of this
section.
Display Reading Cause of Fault Function Response
Abbreviation Definition
*
[1]
[2]
[3]
Optional item
Past production
Current production
Maximum angle at which boom will stop varies
with each attachment. See Boom Stop
Adjustment in Section 4 of this manual for
maximum angle at which boom stops.
+
-
%
A1
A2
A3
ANG
AUX
BHITCH
CLAM
CTWT
D1
D2
D3
DEG F
HYD
LUFF
MIN
MAX
MXR
PRESS
PSI
PSIA
RPM
SYS
TEMP
Plus
Minus
Percent
Handle Inputs
Pump Control Outputs
Programmer’s Screen
Angle
Auxiliary
Backhitch
Clamshell
Counterweight (MAX-ER)
On-Off Inputs
Digital Inputs
Digital Inputs or Outputs
Degrees Fahrenheit
Hydraulic
Luffing
Minimum
Maximum
MAX-ER 2000
Pressure
Pounds Per Square Inch
Pounds Per Square Inch Absolute
Revolutions Per Minute
System
Temperature
