Procedures for Testing with the DX Host
62 Baker DX 71-030 User Guide EN V10 www.megger.com
NOTE: In an assembled motor, the rotor’s position will influence the stator coil inductances. When looking
for imbalances and comparing to previous values, be sure to take into account the rotor position, or remove
the rotor to eliminate the effect.
RLC Test Procedure Overview
The general test procedure for RLC testing includes the following steps:
1. Connect low-voltage RLC test leads.
2. Select RLC mode.
3. Select Resistance test.
4. Touch and release PTT.
5. Select Inductance mode.
6. Select test frequency.
7. Touch and release PTT.
8. Configure low-voltage test leads for capacitance testing.
9. Select Capacitance mode.
10. Touch and release PTT.
11. Save results.
12. Disconnect low-voltage test leads.
