Chapter 5 Using the XY Slitter
131
2
Lower the XY clamp lever.
• The XY carriage can be moved by hand when the XY clamp lever is lowered.
3
Move the X cutter to the side and raise the X cutter lever to secure it.
• Avoid touching the cutter blade. Failure to do so may result in injury.
4
Press to feed the media to a position approximately 300 mm from the bottom face of the
front cover, then press the [ENTER] key.
5
Engage the media on to the tension bar and pull it out from the bottom.
5
To Next Page
