Chapter 8 Troubleshooting
230
5
Input the numerical value of the position with the lowest vertical misalignment.
•
Enter "-0.4 mm" as "-4", as shown in the illustration below.
-2
-5
-4
-3
-6
Enlarged X
6
Input the numerical value of the position with the lowest horizontal misalignment.
•
Enter "0.2 mm" as "2", as shown in the illustration below.
4
1
2
3
0
Enlarged Y
