Chapter 9 Appendix
246
Item JV330 Series CJV330 Series TS330-1600
200 to 240 V AC: Max. 1,440 W
Standar
d
Inlet 1 800 W
Inlet 2 750 W -
Minimu
m
*15
Inlet 1 4.5 W or less
Inlet 2 ---- -
Installat
ion
environ
ment
*16
Permissible
ambient
temperature
20 to 30 °C
Relative humidity 35 to 65 %RH (no condensation)
Temperature
range in which
accuracy is
guaranteed
20 to 25 °C
Temperature
gradient
Not more than ±10 °C/h
Dust
0.15 mg/m
3
(typical office)
Maximum
operating altitude
2,000 m (6561.7 ft)
Externa
l
dimensi
ons
*17
Width 160 size: 3,170 mm (3,550 mm)
130 size: 2,920 mm (3,300 mm)
3,170 mm (3,550 mm)
Depth 1,215 mm (1,130 mm) 820 mm (1,130 mm)
Height 1,305 mm (950 mm)
Weight
*
17
160 size 368 kg (460 kg) 373 kg (468 kg) 240 kg (300 kg)
130 size 358 kg (453 kg) 363 kg (458 kg) -
*1. The XY slitter is limited to the types of media that can be used with it. "Specifications (XY
Slitter)"(P. 248)
*2. With setup menu margins set to the minimum (5 mm) on either side.
*3. External diameter and weight after winding media.
*4. 120 to 200 mm when the (take-up unit) media edge guide is used (depending on the position of the edge
guide).
*5. Free of sagging due to weight.
*6. 3 inch only for high-speed printing.
*7. Excluding media size variation and initial loading fluctuations.
*8. Partial switch supported. Including clamp off.
*9. Excluding V-shaped cutting.
*10. Printing is not possible if local guidance shows any speed other than "1000Mbps". "Using a LAN
Cable"(P. 39)
*11. The print speed may be decreased depending on the connection environment or print data.
"Connecting a PC to the Product"(P. 39)
*12.
*13. Excluding options.
*14. Varies depending on print mode.
*15. In sleep.
*16. Ink ejection consistency may decrease in conditions outside this range.
*17. The figures in parentheses indicate package dimensions. Excluding the media chute.
To Next Page
