Chapter 3 Cutting
98
Installing the Cutter Holder
1
On the LOCAL mode screen, select [MENU] > [Cutting], then press the [ENTER] key.
• The Cutting menu is displayed.
2
Select [Tool Change], then press the [ENTER] key.
3
Open the maintenance cover on the left side.
• The cutter unit can be moved manually. Move the carriage slowly to a position allowing
easy access while working.
4
Turn the knob screw and loosen the holder presser.
5
Insert the cutter holder into the tool holder.
• Push the brim of the cutter holder against the holder presser.
6
Secure the cutter holder.
• Turn the knob screw to secure the holder presser. Failure to secure firmly may result in lower
quality.
To Next Page
