Special Imaging Modes
11-18
Parameter Description
Quick Rot.
To quick rotation the 3D image.
Selection: 0°, 90°, 180°, 270°.
Direction To set the fast view direction when entering viewing mode.
Reset Curve To reserve the VOI edge line to be plane.
Auto Rotation Function: to open 3D image auto rotation function.
Return Function: to return to Smart3D acquisition preparation
In Smart3D image viewing, the system supports the following functions:
z Press <Freeze> on the control panel to return to image acquisition preparation status.
z Click [Return] on the menu to return to image acquisition preparation status.
z Parameters adjustment in 3D image rendering.
z B-mode parameters adjustment. (Switch to B image mode via the left or right key of
the 4-directions key, then adjust colorize, gray map, curve, rejection, γ.)
z Set the display format.
z View the sectional plane
z Define VOI box size and position.
z Rotate 3D image
z Image zooming
z Image cutting.
z 3D image parameters adjustment.
z Reset ROI
z Reset image: reset the image to the initial status if there is any rotation, position
changing or magnification.
Enter/Exit 3D image viewing
To enter 3D image viewing:
The system enters image viewing when image acquisition is finished. You can
complete the acquisition by pressing [Update] or [Freeze] key or clicking [Stop] on the
menu; or, wait until the 3D capture automatically completed.
Exit
Press [Freeze] or [Esc] key or Click [Return] on the menu to return to Smart3D image
acquisition preparation status.
Set the display format
Image display format: click [Disp Format] on the menu to set the image display format,
each adjustment cycles you to the next setting. Or you can directly press <Dual> or
<Quad> to performing window switching. Here,
