[Zerotrack range]
Range within which automatic zero tracking compensates deviations.
Setting range: 0.2510000.00 d
In "legal-for-trade" mode a value of 0.25 d has to be entered.
[Zerotrack step]
If a weight change exceeds the adjusted value, automatic tracking does not function any
more.
Setting range for automatic tracking increments: 0.2510 d
In "legal-for-trade" mode a value of 0.25 d has to be entered.
[Zerotrack time]
Time interval for automatic zero tracking.
Setting range: 0.125 s
At 0.0 s the zero tracking is switched o.
For use in legal metrology a value of 1 s must be entered.
[Overload]
Weighing range above the maximum load (Max) without error message.
Setting range: 09999999 d
For use in legal metrology a value of max. 9 d = e must be set.
[Minimum weight]
Minimum weight at which a print command can be triggered.
Setting range: 09999999 d
For use in legal metrology a value of at least 20 d must be set.
[Range mode]
Selection: <Single range>, Multiple range, Multi-interval
For scale range selection, see Chapter 7.12.15.2 and 7.12.15.3.
Press the softkey to exit the menu and to save the settings.
7.12.15.1 Legal-for-trade mode
In the menu -[Weighing point]- [Calib]- [Param]- [W&M] you can choose between
[none] and the legal-for-trade modes [OIML], [NTEP], or[ NSC].
[none] [OIML] [NTEP] [ NSC]
Gross weight
display
B B G G
0.125 mV/V @
30,000 d
0.125 mV/V @
3000 e
0.125 mV/V @
3000 e
0.125 mV/V @
3000 e
0.25 mV/V @
60,000 d
0.25 mV/V @
6000 e
0.25 mV/V @
6000 e
0.25 mV/V @
6000 e
Recommended
min. measure-
ment signals
0.42 mV/V @
10,000 e
0.42 mV/V @
10,000 e
0.42 mV/V @
10,000 e
If legal-for-trade mode is switched on, the parameter settings (zero tracking etc.) must be
selected accordingly. The device does not peform a check of this.
The CAL switch (see Chapter 7.1.3.1) must be sealed in the closed position.
