V304 is lit:
The current limit for the load cell supply is activated.
Causes:
- There is a short circuit in the load cell supply lines
- The load cell resistance is too low (e.g.too many load cells connected)
Current limiting at >96 mA
WARNING
Working on the device while it is switched on may have life-threatening
consequences.
When removing covers or parts using tools, live parts or terminals may be exposed.
Please note that capacitors in the device may still be charged even after disconnecting
the device from all voltage sources.
Disconnecting the device from the power supply.
Disconnect the device from the power supply and eliminate the fault.
After the fault is eliminated it may be necessary to switch o the device and/or
disconnect the load cells in order to deactivate current limiting.
16.8 Error numbers @ "LAST_ERROR"
16.8.1 Weighing point error
Number Display Cause
2 in use Weighing point is in use, e.g., by an application.
6 test active Test is active, no weights.
7 cali active Calibration is active, no weights.
8 no standstill No standstill of the scale.
13 tare is active Tare is active.
15 weight is dimmed Weight is not legal-for-trade (<0 or >max.).
16 weight has error Weight error.
17 scale not ready Scale is not ready.
18 cannot tare below zero Taring below zero is not possible.
102 timeout Only on xBPI scales: Time limit exceeded when sending a com-
mand to the scale.
142 calibration active During calibration, taring and zeroing is not possible.
147 no zeroset Zeroset outside of the zero setting range is not possible.
149 Busy The scale is currently busy with another query.
255 hardware error Weighing point is faulty.
Transmitter in eld housing PR 5230 16 Error messages
Minebea Intec EN-292
