For reset, the bit number + 128 (208255) is written to Write_Value_Select.
Action of the master Reaction of the PR 5230
Write register number to
Write_Value_Select.
Write Write_Value to the selected re-
gister.
Write Write_Value to the selected re-
gister.
Set the Write_Active bit.
Wait until Write_Active has been set.
Write 0 to Write_Value_Select.
Reset the Write_Active bit.
12.2.4.4 Reading bit
Single bits can be read only by reading a register. The procedure is described in
Chapter 12.2.4.3.
12.2.4.5 Control byte
Some device functions can be executed by setting bits in the input area directly.
Action of the master Reaction of the PR 5230
Bits in Control Byte set.
The operation is processed.
Reset bits in the Control Byte. Copy Read_Value_Select to
Read_Value_Selected.
12.2.4.6 Waiting for the result of the action
When an action taking a longer time was started, the end of execution can be waited for
after starting (see Chapters 12.2.4.3 and 12.2.4.5).
Action of the master Reaction of the PR 5230
For setting bits, see Chapters 12.2.4.3
and 12.2.4.5.
Acknowledge the "set bit" (see Chap-
ter 12.2.4.3).
Set the CmdBusy bit.
The operation is processed.
In the event of an error: Set the
CmdError bit and the LastError byte.
Reset the CmdBusy bit.
Wait until CmdBusy has been reset.
Check the CmdError bit.
