SPM address Type of data R/W Function
D67 DINT R EasyFill only: "Last_Error" error, see Chapter 16.8.2
OPC server only
R264 REAL R Gross value (as oat)
R265 REAL R Net value (as oat)
R266 REAL R Tare value (as oat)
R267 REAL R Current gross/net selected by X72 (as oat)
R270 REAL R Max. value from scale (FSD) (as oat)
R271 REAL R Min. value from scale (as oat)
R272 REAL R Report: Gross value (as oat)
R273 REAL R Report: Net value (as oat)
R274 REAL R Report: Tare value (as oat)
R280 REAL R Standard application only: Limit: Limit 1 on (as oat)
R281 REAL R Standard application only: Limit: Limit 1 o (as oat)
R282 REAL R Standard application only: Limit: Limit 2 on (as oat)
R283 REAL R Standard application only: Limit: Limit 2 o (as oat)
R284 REAL R Standard application only: Limit: Limit 3 on (as oat)
R285 REAL R Standard application only: Limit: Limit 3 o (as oat)
R287 REAL R/W Write the value in the preset tare memory (as oat).
Note:
The system variables (e.g., ST_WGT_A) for the communication via OPC are described in the operating
instructions PR 1792 (Chapters 4 + 5).
Example:
Production start
Write material parameters (D44D49).
Start lling (X1168).
Monitor status (B144, B145).
Read report data when lling is complete.
Transmitter in eld housing PR 5230 13 SPM
Minebea Intec EN-282
