NOTICE
The cable colors shown above are valid for a CAPP4 500 x 400 and a
CAPP1 320 x 420.
The assignments of cable colors are listed in the load platform operating
instructions.
Connection designations
Combics 13-devices
PR 5230
BR_POS V+ Supply
SENSE_POS S+ Sense
OUT_POS M+ Meas.
OUT_NEG M- Meas.
SENSE_NEG S- Sense
BR_NEG V- Supply
The cable screens must be connected in the cable gland of the device. If the measuring
lines (+M, -M) are screened individually, these screens must be connected to the GND on
the terminal block as well.
Transmitter in eld housing PR 5230 4 Device installation
Minebea Intec EN-72
