Mitel 6940 - Configuring a Blf;List Key Using the Mitel Web UI

Configuring Softkeys
cix
Configuring a BLF/List Key Using the Mitel Web UI
If you set a key to use BLF/List, you must also enter a BLF List URI at Operation > Softkeys and
XML > Services
. The BLF List URI is the name of the BLF list defined on the Busy Lamp field page
for a particular user. For example, sip:9@192.168.104.13. The value of the
BLF List URI parameter
must match the list name configured. Otherwise, no values display on the 6940 screen and the
feature is disabled.
1. Click on Operation > Softkeys and XML .
or
Click on
Operation > Expansion Module <N> .
Softkeys
2. Select from Key 1 through Key 48 on the Top keys.
3. In the Type field, select BLF/List .
4. In the Line field, select a line number that is actively registered to the appropriate SIP proxy
you are using. Valid values are:
• global
Unknown
Not monitored
BLF/List State Softkey Icon
