Mitel 6940 - Softkey Display Behavior

Mitel 6940 SIP Phone User Guide
xcvi
The following table identifies the applicable default states for each softkey type on the IP phone.
In the Mitel Web UI, the operational states for each softkey display as enabled. To disable a state,
simply uncheck the box for the respective state.
Softkey Display Behavior
On the 6940 IP phone, you can configure up to 48 (top) and 30 (bottom) functions on the softkeys.
By default, if you have no softkeys configured on the IP phone, and you assign softkey functions to
higher number keys in the Mitel Web UI, the key functions automatically appear in the first available
position on the LCD display.
For example, if top softkeys 1 through 48 are set to
None , and you set the top softkey 12 as the
following:
Softkey Type Default States
None All states disabled.
Speed Dial Idle, Connected, Incoming, Outgoing, Busy
DND Idle, Connected, Incoming, Outgoing, Busy
XML Idle, Connected, Incoming, Outgoing, Busy
Flash All states disabled.
Sprecode Connected
Park Connected
Pickup Idle, Outgoing
Last Call Return Idle, Connected, Incoming, Outgoing, Busy
Call Forward Idle, Connected, Incoming, Outgoing, Busy
Speed Dial/Xfer Idle, Connected, Incoming, Outgoing, Busy
Speed Dial/Conf Idle, Connected, Incoming, Outgoing, Busy
Speed Dial/MWI Idle, Connected, Incoming, Outgoing, Busy
Directory Idle, Connected, Incoming, Outgoing, Busy
Filter Idle, Connected, Incoming, Outgoing, Busy
Received Callers List Idle, Connected, Incoming, Outgoing, Busy
Outgoing Redial Idle, Connected, Incoming, Outgoing, Busy
Conference Idle, Connected, Incoming, Outgoing, Busy
Transfer Idle, Connected, Incoming, Outgoing, Busy
Intercom Idle, Connected, Incoming, Outgoing, Busy
Phone Lock All states disabled.
Paging All states disabled.
Login Idle, Connected, Incoming, Outgoing, Busy
Discreet Ringing Idle, Connected, Incoming, Outgoing, Busy
Call History Idle, Connected, Incoming, Outgoing, Busy
Empty Idle, Connected, Incoming, Outgoing, Busy
