MANUAL TRANSMISSION OVERHAUL – Output Shaft
22B-31
"GA 2ND SPEED GEAR SLEEVE INSTALLATION
"HA 3RD SPEED GEAR INSTALLATION
"IA SNAP RING INSTALLATION
Select and install a snap ring so that the output shaft 3rd
speed gear clearance will have the standard value.
Standard value: 0 – 0.09 mm
"JA 4TH SPEED GEAR INSTALLATION
"KA 5TH SPEED GEAR SLEEVE INSTALLATION
2nd speed
gear sleeve
MD998364
MD998824
MD998812
MD998814
3rd speed gear
MD998364
MD998824
MD998812
MD998814
Snap ring
4th speed
gear
MD998364
MD998812
MD998813
MD998821
5th speed
gear sleeve
MD998364
MD998812
MD998813
MD998821
