SAFETY INSTRUCTIONS
© 2014 Mold-Masters (2007) Limited. All Rights Reserved.
Revised 1 Oct, 2014
3-2
3.3 Check your wiring
Before you energise the system, pay special attention to how the sup-
ply to your controller is wired and how it is connected to the mold.
Lack of attention to detail causes errors such as:
• Incorrect wiring of mains supply phases into the controller.
• Crossing heater supply feeds with thermocouple detection (al-
though this error can be eliminated by the adoption of
Mold-Masters Standard connections).
In such cases wiring errors have caused equipment failure.
Mold-Masters (UK) Ltd. cannot be responsible for damage caused to
the controller by customer wiring and/or connection errors.
3.4 Mold Heating
After the consoles have started and the main display screen is visi-
ble then the controller may, or may not, start to heat up the zones; it
depends on how the Console Startup option is congured. (See page
5-19.)
If Console startup is set to “Stop” then the tool remains at zero pow-
er and at room temperature. If it set to any of the other three options
(Startup, Standby, or Run) the controller applies power to the zones
so that they heat up.
