Moons' MBDV Series - Page 134

134
Rev. 2.0
07/27/2023
MBDV Hardware Manual
Parameter Instruction Name Defaults Range Unit
Related
Patterns
P1-16 DA RS-485 communication address 32 1 ~ 32 - P S T
In Modbus/RTU communication mode, set the node address of the drive
Parameter Instruction Name Defaults Range Unit
Related
Patterns
P1-17 CO
CAN open communication node
address
1 1 ~ 127 - P S T
In CAN open communication mode, set the drive node address
Parameter Instruction Name Defaults Range Unit
Related
Patterns
P1-18 CB CAN open communication baud rate 0 0 ~ 7 - P S T
When the DIP switch for setting the CANopen communication baud rate on the drive is set to OFF, this parameter can be congured
via the Luna Software to set the CANopen communication baud rate. After this value is congured, it will be saved immediately but will
not take e󰀨ect until the next power-on which means the host computer software can congure this value at any time.
Set value Speed
0 1 Mbps
1 800 kbps
2 500 kbps
3 250 kbps
4 125 kbps
5 50 kbps
6 20 kbps
7 12.5 kbps
Parameter Instruction Name Defaults Range Unit
Related
Patterns
P1-19 ZR Regenerative resistor resistance 200 10 ~ 32000
Ω
P S T
Set the resistance value of the regenerative energy absorption resistor, and the driver calculates the discharge power on the
regeneration resistor according to the current discharge voltage and resistance value. The default value is the resistance value of the
regenerative energy absorption resistor built into the driver. When using an external regenerative energy absorption resistor value, the
correct resistance value must be set.
Parameter Instruction Name Defaults Range Unit
Related
Patterns
P1-20 ZC Regenerative resistor power rating 40 1 ~ 32000 W P S T
Sets or requests the regeneration resistor wattage value. MBDV drives dynamically calculate the continuous wattage induced into
an external regeneration resistor and must know the continuous wattage rating of the regen resistor to do this e󰀨ectively and avoid
damaging the resistor.
Parameter Instruction Name Defaults Range Unit
Related
Patterns
P1-21 ZT Regenerative resistor time constant 1000 0 ~ 8000 ms P S T
Sets or requests the regeneration resistor time constant. Decides the peak time that the resistor can tolerate full regeneration voltage.
Parameter Instruction Name Defaults Range Unit
Related
Patterns
P1-24 MA Alarm mask 4294967295 0 ~ 4294967295 - P S T
When the driver generates some non-serious warning information, the corresponding bit of this parameter can shield the LED alarm
display function of the corresponding warning information. When the shielded warning information is generated, it will no longer ash
on the two 7 - segment digital tubes.
