4 - 8 MC92N0-G User Guide
5. Remove the battery from the RS507.
6. Re-install the battery into the RS507.
7. On the MC9200-G, touch .
8. Touch Bluetooth.
9. Touch SCAN FOR DEVICES. The device begins searching for discoverable Bluetooth devices in the area and
displays them under AVAILABLE DEVICES.
10. Scroll through the list and select RS507.
The device connects to the RS507 and Connected appears below the device name. The Bluetooth device is
added to the Bluetooth devices list and a trusted (“paired”) connection is established.
Pairing the RS507 Hands-Fee Imager Using Android SSI
An RS507 Hands-free Imager can be used with the device to capture bar code data.
1. Ensure that the two devices are within 10 meters (32.8 feet) of one another.
2. Install the battery into the RS507.
3. On the MC92N0, touch .
4. Touch .
Figure 4-7
Bluetooth Pairing Utility
5. Using the RS507, scan the bar code on the screen.
The RS507 emits a high/low/high/low beeps. The Scan LED flashes green indicating that the RS507 is
attempting to establish connection with the MC92N0. When connection is established, the Scan LED turns off
and the RS507 emits one string of low/high beeps.
6. On the MC92N0, touch .
