Motorola MC92N0-G User Manual

2 - 20 MC92N0-G User Guide
Fusion Setup
For detailed WLAN setup using Fusion, refer to the Wireless Fusion Enterprise Mobility Suite User Guide for
Version X2.01.
To setup WLAN using Fusion:
1. Tap the > Wireless Companion > Wireless Launch > Manage Profiles. The Manage Profiles window
appears.
2. Tap and hold in the window and select Add from the pop-up menu. The Wireless LAN Profile Entry window
appears.
3. In the Profile Name text box enter a name for the profile.
4. In the ESSID text box enter the ESSID.
Figure 2-17 Profile ID Dialog Box
5. Tap Next. The Operating Mode dialog box displays.
6. In the Operating Mode drop-down list, select Infrastructure or Ad-hoc.
Wireless Status Invokes the Wireless Status application which allows the user to view the
status of the current wireless connection.
Wireless Diagnostics Invokes the Wireless Diagnostics application which provides tools with
which to diagnose problems with the wireless connection.
Log on/off Invokes the Network Login dialog which allows the user to log on to a
particular profile or to log off from the currently active profile
Fusion Help Invokes Fusion Help application which provides on-device Help.
Table 2-9 Supported Applications (Continued)
Application Description
NOTE Obtain the proper WLAN configuration information from the system administrator prior to performing the
Fusion setup procedures.
The following setup procedure example shows setup of a WLAN using Wired Equivalent Privacy (WEP)
encryption.

Motorola MC92N0-G Specifications

General

Brand	Motorola
Model	MC92N0-G
Category	Barcode Reader
Language	English
