5 - 4 MC92N0-G User Guide
Bluetooth Power States
Table Table 5-3 list the state of the Bluetooth stacks after a warm or cold boot.
Suspend
When there is an active Bluetooth connection, the Bluetooth radio goes into low power mode maintaining the active
connection. When there is no active connection, the Bluetooth radio turns off.
With StoneStreet One Bluetooth Stack
With Microsoft Bluetooth Stack
Resume
When the MC92N0-G resumes, Bluetooth turns on if it was on prior to suspend.
•
MotoBTUI Application
•
Use the MotoBTUI application to:
•
Turn the Bluetooth radio on and off. See
•
View device information.
•
Control device status
•
Generate a pairing bar code (See Using the RS507 Hands-free Imager on page 10-19 for more information).
•
Configure FIPS key.
Table 5-3
Bluetooth Power States
After a
Windows
Embedded
Handheld
Bluetooth Stack
Windows
Embedded
handheld Stone
Street Bluetooth
Stack
Windows CE
Microsoft
Bluetooth Stack
Windows CE
Stone Street
Bluetooth Stack
Warm Boot Retains state Retains state Retains state Retains state
Cold Boot Retains state Retains state Does not retain state Does not retain state
NOTE If there is an active Bluetooth connection between the MC92N0-G and another Bluetooth device, the
MC92N0-G will not timeout. However, if the user presses the Power button on the MC92N0-G, the
MC92N0-G will suspend and upon receiving data from a remote Bluetooth device, the MC92N0-G will wake
from suspend mode. For example, Bluetooth scanner sending data to the MC92N0-G.
NOTE If there is an active Bluetooth connection between the MC92N0-G and another Bluetooth device and there is
no data activity, the MC92N0-G will timeout. However, if the user presses the Power button on the
MC92N0-G, the MC92N0-G will suspend and upon receiving data from a remote Bluetooth device, the
MC92N0-G will wake from suspend mode. For example, headset redial or Bluetooth scanner sending data to
the MC92N0-G.
