Motorola MC92N0-G - Entering Data; Using a Wired Headset

1 - 12 MC92N0-G User Guide
Entering Data
When entering data on the keypad, use either the single-hand method or the two-hand method as shown in Figure
1-9.
Figure 1-9 Entering Data on the Keypad
Using a Wired Headset
You can use a mono headset for audio communication when an audio enabled application is used. To use a
headset, plug the headset jack into the audio connector on the side of the MC92N0-G. Ensure that the
MC92N0-G’s volume is set appropriately before putting the headset on. When a headset is plugged into the jack,
the speakerphone is muted.
Zebra recommends a 2.5mm jack headset. See Table 7-1 on page 7-1 for available Zebra headsets.
Single-hand Method
Two-hand Method
