Operating the MC92N0-G with Android OS 3 - 27
Notification Icons
Indicates the current state of the PTT Express Voice client.
Selecting a Talk Group
One of 32 Talk Groups can be selected by PTT Express users. However, only one talk group may be enabled at a
time on the device. Touch one of the 32 Talk Groups. The selected Talk Group is highlighted.
PTT Communication
PTT communication may be established as a Group Call or Private Call. When PTT Express is enabled, the
buttons on the left side of the device are assigned for PTT communication. When the Wired Headset is used,
Group Calls and Private Calls can also be initiated using the headset Talk button.
Figure 3-25
PTT Buttons
Table 3-7
PTT Express Default User Interface Descriptions
Status Icon Description
Indicates that PTT Express Voice client is disabled.
Indicates that PTT Express Voice client is enabled but not connected to a WLAN.
Indicates that PTT Express Voice client is enabled, connected to a WLAN and listening on the Talk
Group indicated by the number next to the icon.
Indicates that PTT Express Voice client is enabled, connected to a WLAN and communicating on
the Talk Group indicated by the number next to the icon.
Indicates that PTT Express Voice client is enabled, connected to a WLAN and in a private
response.
Indicates that PTT Express Voice client is enabled and muted.
Indicates that the PTT Express Voice client is enabled but it is not able to communicate due to a
VoIP telephony call is in progress.
NOTE This section describes the default PTT Express client configuration. See the PTT Express V1.2 User
Guide for detailed information on using the client.
Group Call
Button
Private Call
Button
